型号参数
电线之保护与绝缘。
端子与电接线头之绝缘与保护。
分色作用。
防水。
电阻电容器之保护与绝缘
标志颜色（透光）：黑、白、红、蓝、黄、绿、棕、灰、橙、紫。 |
| 技术参数 |
| Honco No. |
Type |
As Supplied |
After Shrinkage |
Packing
(M/Roll) |
| I.D(mm) |
Thickness |
I.D(mm) |
Thickness |
| HC013-001 |
HC-1
|
1.0 |
0.2±0.05 |
0.5 |
0.4±0.05 |
400 |
| HC013-002 |
HC-1.5 |
1.5 |
0.2±0.05 |
0.75 |
0.4±0.05 |
300 |
| HC013-003 |
HC-2 |
2.0 |
0.25±0.05 |
1.0 |
0.45±0.1 |
200 |
| HC013-004 |
HC-2.5 |
2.5 |
0.25±0.05 |
1.25 |
0.45±0.1 |
100 |
| HC013-005 |
HC-3 |
3.0 |
0.25±0.05 |
1.5 |
0.45±0.1 |
| HC013-006 |
HC-3.5 |
3.5 |
0.25±0.05 |
1.75 |
0.45±0.1 |
| HC013-007 |
HC-4 |
4.0 |
0.25±0.05 |
2.0 |
0.45±0.1 |
| HC013-008 |
HC-5 |
5.0 |
0.35±0.05 |
2.5 |
0.55±0.1 |
| HC013-009 |
HC-6 |
6.0 |
0.35±0.05 |
3.0 |
0.55±0.1 |
| HC013-010 |
HC-7 |
7.0 |
0.35±0.05 |
3.5 |
0.55±0.1 |
| HC013-011 |
HC-8 |
8.0 |
0.35±0.05 |
4.0 |
0.55±0.1 |
| HC013-012 |
HC-9 |
9.0 |
0.35±0.05 |
4.5 |
0.55±0.1 |
| HC013-013 |
HC-10 |
10.0 |
0.35±0.05 |
5.0 |
0.60±0.1 |
| HC013-014 |
HC-11 |
11.0 |
0.35±0.05 |
5.5 |
0.60±0.1 |
| HC013-015 |
HC-12 |
12.0 |
0.35±0.1 |
6.0 |
0.70±0.1 |
| HC013-016 |
HC-13 |
13.0 |
0.35±0.1 |
6.5 |
0.70±0.1 |
| HC013-017 |
HC-14 |
14.0 |
0.35±0.1 |
7.0 |
0.70±0.1 |
| HC013-018 |
HC-15 |
15.0 |
0.35±0.1 |
7.5 |
0.70±0.1 |
50 |
| HC013-019 |
HC-16 |
16.0 |
0.35±0.1 |
8.0 |
0.70±0.1 |
| HC013-020 |
HC-17 |
17.0 |
0.35±0.1 |
8.5 |
0.70±0.1 |
| HC013-021 |
HC-18 |
18.0 |
0.4±0.1 |
9.0 |
0.80±0.1 |
| HC013-022 |
HC-20 |
20.0 |
0.5±0.1 |
10.0 |
0.90±0.1 |
| HC013-023 |
HC-22 |
22.0 |
0.5±0.1 |
11.0 |
0.90±0.1 |
| HC013-024 |
HC-25 |
25.0 |
0.5±0.1 |
12.5 |
0.90±0.1 |
| HC013-025 |
HC-28 |
28.0 |
0.5±0.1 |
14.0 |
0.90±0.1 |
| HC013-026 |
HC-30 |
30.0 |
0.5±0.1 |
15.0 |
1.00±0.2 |
| HC013-027 |
HC-35 |
35.0 |
0.5±0.1 |
17.5 |
1.00±0.2 |
| HC013-028 |
HC-40 |
40.0 |
0.5±0.1 |
20.0 |
1.00±0.2 |
25 |
| HC013-029 |
HC-50 |
50.0 |
0.5±0.1 |
25.0 |
1.00±0.2 |
| HC013-030 |
HC-60 |
60.0 |
0.6±0.1 |
30.0 |
1.20±0.2 |
| HC013-031 |
HC-70 |
70.0 |
0.6±0.1 |
35.0 |
1.20±0.2 |
| HC013-032 |
HC-80 |
80.0 |
0.6±0.1 |
40.0 |
1.20±0.2 |
| HC013-033 |
HC-90 |
90.0 |
0.6±0.1 |
45.0 |
1.30±0.2 |
| HC013-034 |
HC-100 |
100.0 |
0.7±0.1 |
50.5 |
1.30±0.2 |
| HC013-035 |
HC-150 |
150.0 |
0.8±0.1 |
75.0 |
1.60±0.2 | |
|
